Anycubic Photon M3 Premium MSLA 8K Resin 3D Printer
Anycubic Photon M3 Premium, new resin 3D printer with the highest resolution in the M3 series ever. It features a 10-inch 8K LCD screen resolution, a new UV light system LighTurbo 2.0, and a large build volume. These advanced technologies allow the M3 Premium to produce high-quality prints, and its user interface ensures a seamless workflow.
Anycubic Photon M3 Premium (8K) Main features & Highlights
- 10" Monochrome LCD screen with 8K resolution
- LightTurbo 2.0 new technology with cooling system
- Large build size
- Double threaded ball screw
- Anycubic smart cloud
- Large resin VAT with NFEP film
- Dual air purifier filters
10" MONOCHROME LCD SCREEN WITH 8K RESOLUTION
The Anycubic Photon M3 Premium comes with an 8K Monochrome LCD screen that gives 7,680 × 4,320 pixels and 28.5um XY resolution—and when combined with its incredible 380:1 contrast ratio user can effortlessly create crisp textures and detailed prints.
LIGHTTURBO 2.0 NEW TECHNOLOGY WITH COOLING SYSTEM
The LightTurbo 2.0, a self-innovated patented solution by Anycubic that combines the high light uniformity of COB systems with a source of illumination free from stray light and thus able to generate delicate and smooth surfaces on models. The LightTurbo 2.0's 1.26% stray light level is lower than 3.47% on the COB Light source with a Fresnel lens, thus allows Anycubic Photon M3 Premium to produce more consistent print results. The Anycubic Photon M3 Premium has sensors at the back of its COB lighting system, which detects temperature. When the temperature of the system exceeds 65°C, a cooling fan will activate to help lower its temperature. The heat sinks on both sides of the COB light source help it dissipate excess heat so that its working temperature is within 65°C, thereby extending its life.
LARGE BUILD SIZE
The Anycubic Photon M3 Premium offers a build size of 25 x 22 x 12 cm. Anycubic Photon M3 Premium is designed with larger build plate and more efficient cooling, so they can produce models up to 35% larger than their competitors without sacrificing resolution.
DOUBLE THREADED BALL SCREW
The Ball Screw Mechanism with Two Linear Rails installed in the Z-axis provides a smoother, more accurate mechanism. The Z-axis runs on two linear rails and features a ball screw mechanism, making it twice as accurate as the T-screw structure but with similar lifting capabilities. This means that layer lines are eliminated while maintaining accuracy of 0.005mm. With a print speed of up to 95mm/h, M3 Premium is the fastest 3D printer in its class. Compared with other 8K models, which have lead screw mechanisms that take longer than 2 hours per 12cm model, this accelerated time could save users as much as 2.5 hours printing time when creating large objects such as large cosplay or architectural props
ANYCUBIC SMART CLOUD
The Anycubic Photon M3 Premium can be operated remotely via the Anycubic Smart Cloud App—which offers access to a library of over 20,000 downloadable STL files
LARGE RESIN VAT WITH NFEP FILM
A 60% larger resin tank reduces the frequency that you need to refill your resin when printing large, complex objects. This is compared with traditional FEP film, NFEP film makes it easier to separate prints from the build plate and increases overall success rates by 10%.
DUAL AIR PURIFIER FILTERS
Dual air purifier systems filters out fumes from the resin 3D printer. The design of these symmetrical purifiers makes it more efficient than using a single unit to filter air, because the larger outlet area means that there is more surface area through which impurities can be collected and cleaned away by fans on each system.
Anycubic Photon M3 Premium Technical specifications
|Model / Product name||Anycubic Photon M3 Premium|
|Z-axis||dual linear rails, ball screw|
|Resin Tank||Unibody design with scale lines|
|Resin||Standard, Water-Washable, and ABS-like UV Resin|
|Build Platform||Laser Carved Metal|
|Exposure Screen||10.1" monochrome(7.680x4.320 px, 28.5um XY Resolution)|
|Light Source||Anycubic LighTurb 2.0 Light Source|
|Power Supply||150W rated power|
|Control Panel||4.3" TFT touch-control|
|Data input||USB Type-A2.0/ Wi-Fi Port|
|Machine Leveling||4-point manual leveling|
|Machine Dimensions||25*13*14 in. / 63*33*35cm (HWD)|
|Printing Dimensions||9.9*4.9*8.6 in. / 250*123*219 mm(HWD)|
|Machine Weight||19kg / 41lb.|
