Geeetech A10M 3D Printer
Mix Color 3D Printing/Dual Extrusion 2 IN 1 OUT
This is the most updated version with new motherboard & the LCD!
Highlights
- Geeetech A10M 3D printer, adopting new open source GT2560 control board V3.0, delivers mix-color objects and greatly enriches your 3D printing life. Keeping the good performance of its predecessor A10, it aims to provide users with quality printout and satisfactory printing experience.
- The modularized design provides you with an easier assembly experience. Its classic blue and black color combo imparts a touch of simplicity and excellence, embodying Geeetech’s commitment to quality products.
- Keeping Prusa I3 3D printers’ gantry structure and with its build volume as 220*220*260mm³, A10M makes the best of the building platform and enables you to view the printing details in 360°. Printing at the accuracy of 0.1mm, it delivers objects with smooth surface finish, clear angles and strong structure. Besides, A10M comes with filament detector and break-resuming capability, greatly enhancing your 3D printing experience.
- Its well-designed extruder greatly reduces the risk of clogging or leaking. A10M extruder cover features 360°ventilation design, greatly enhancing the dissipation of heat and guaranteeing excellent printing quality.
- A10M extruder motor uses a gear train of 3:1 speed ratio, amplifying input torque and improving your printing experience. Adopting the modularized design for extruder wiring, A10M makes it easy to exchange the wire.
- The V-shaped wheels and rails on each axis, made from wear-resistant aluminum profile, could, in a large measure, reduce the printing noise and offer you a quiet 3D printing environment.
- Power Failure Recovery: The Power Failure Recovery function provides Geeetech A30 the break-resuming capacity. It is added to save real-time printing status and resume the printing job exactly at the same place where it has been stopped. This add-on totally drives away the hassle of repetitive and time-time consuming printing jobs caused by unexpected power outage. Totally get you out of worries about printing large-size 3D models.
- Filament Detector: Filament detector kills the pain caused by filament outage or fracture.The detecting system would alert you to change filament in case the printer would run in air or the spool is empty. This add-on would avoid bootless printing as well as enhancing your printing satisfaction.
- Large Build volume at this price point 220*220*260 mm³
- Optional Auto-leveling upgrade: no need for time-consuming manual bed leveling.
- NEW Upgraded 24V PSU!!
Technical specifications
Printing technology | FDM |
---|---|
Brand | Geeetech |
Model | A10M |
Build volume | 220*220*260 mm³ |
Printing accuracy | 0.1mm |
Positioning precision | X/Y:0.011mm. Z: 0.0025mm |
Printing speed | 120 mm/s (max) |
Filament diameter | 1.75mm |
Nozzle diameter | 0.4mm |
Filament | ABS / PLA /flexible PLA/wood-polymer/PVA/HIPS/PETG, etc. |
Max temp for hotbed | 100C |
Max temp for extruder | 250C |
Operating system | Windows, MAC, Linux |
Control software | EasyPrint 3D, Repetier-Host, Simplify 3D, Cura, Slic3r, etc. |
Remote App | EasyPrint 3D App (with an optional 3D WiFi module) |
File format | .STL, G.code |
Power supply | Input: 115V/230V |
Output | DC 24V, 360W |
Connectivity | Wi-Fi (with an optional 3D WiFi module), USB cable, |
SD card | (support stand-alone printing) |
Display screen | LCD 2004 |
Frame | Aluminum profile |
XY Rods | Wear-resistant aluminum profile |
Z axis | Lead screw |
Stepper Motors | 1.8°step angle with 1/16 micro-stepping |
Machine Dimension | 478 x 413 x 485mm³ |
Shipping box Dimension | 490 x 470 x290 mm³ |
Machine Net weight | 7.96kg |
Machine Gross weight | 9.98 kg |
Buyer Protection Policies
100% Secure Payment
PayPal-the most reliable payment method. Also accepts card payments(PCI DSS Compliant)
DHL,UPS Insured Shipment
High Quality Express Transport without damage.
1 Year Warranty
Just in case. Of course we only ship out perfect products.
Technical Support Service
Experiencing trouble? Feel free to contact us!
Shipping Details
Processing (Lead) Time
Ships in 1 to 2 Business days. Proper Testing & Packaging prior to shipment(100% Quality Control)
Delivery Time to Doorstep (Transit)
4 to 5 days via FedEx/UPS/DHL
Documentation
Mix-Color Prinitng
A10M, coming with Dual extruder module and 2-in-1-out hotend, provides you a printer which has a capability to print 4 types of printings with different color combinations, namely, single color, dual color, graded color and mixed color. A10M will greatly enrich your 3D printing life
4-step Fast Assembly
The Modularised Design of A10M provides you an easier assembly experience. A10M comes almost fully assembled and you just need to fasten several screws before printing your first 3D printing
Break-resuming Capability
The Break-resuming function provides A10M to save real-time printing status and resume the printing job exactly at the same place where it has been stopped. This function totally drives away the hassle of repetitive and time-time consuming printing jobs caused by unexpected power outage. Totally get you out of worries about printing large-size 3D models.
360° Ventilation Design
A10M extruder cover features 360°ventilation design, greatly enhancing the dissipation of heat and improving excellent printing quality.
Filament Detector
Filament detector kills the pain caused by filament outage or fracture.The detecting system would alert you to change filament in case the printer would run in air or the spool is empty. This add-on gadget would avoid bootless printing as well as enhancing your printing satisfaction.
Optional Auto-leveling Sensor
The main board of A10M is professionally coded to support auto-leveling function. All you need is to connect the leveling sensor with it. The whole operation process is effort-saving and would greatly enhance the adhesion of the first layer.
Open Source Control Board
A10M comes with Open Source GT2560 V3.0 control board which provides limitless space for you to modify the firmware at your will. An active 3D printing community will also come into being with our concerted efforts.
High-performance Extruder Gears
A10M extruder motor uses a gear train of 3:1 speed ratio, amplifying input torque and improving your printing experience.
Modularized Extruder Wiring
Adopting the modularized design for extruder wiring, A10M makes it easy to exchange the wire.
Good Adhesion Building Platform
The building platform has the features of High Adhesion and Even Heating. The hotbed heats evenly and can rapidly reach the target temperature. Because of the high adhesion coating on the building plate, it is easy to take down your printings when the hotbed cools off.
V-slot Rails & Wheels
The V-shaped wheels and V-slot rails on each axis make the printing quieter, more stable, and more wear-resistant.
Color-Mixer Software
ColorMixer is applicable for all mix-color printers. It allows you to print graded color between selected layers
