Out Of Stock
$289.00 $169.00 Sale -42% OFF
-
+
  • Brand: ANYCUBIC
  • Product Code: ANYCUBIC-BAY-0186

Anycubic i3 Mega Ultrabase 3D Printer

1 Kg PLA Included.


The Anycubic i3 Mega is a solid, metal-framed 3D printer that comes mostly assembled. Assembly is easy and takes only a few minutes. It has a large build envelope (210 x 210 x 205 mm, or 8.3 x 8.3 x 8.1 inches). The Anycubic i3 Mega also includes some nice advanced features, including:

  • Large build volume: 210 x 210 x 205 mm
  • User friendly 3.5 inch touch-screen interface
  • Can be assembled in just a few minutes
  • Full Rigid Solid metal frame construction and superior stability
  • High quality, accurate printing with layer resolution down to 50 microns
  • Ultrabase
  • Smart manual leveling
  • Filament outage detection with automatic pause when filament runs out and ability to resume after re-load
  • Auto Resume Print from Power Outage
  • Trigorilla Mainboard
  • The device is capable of producing high quality prints, thanks to the stable construction and fine layer resolution down to 0.05 mm. It supports multiple filament materials, including PLA, ABS, High Impact Polystyrene (HIPS) and wood.


Ultrabase


  • Excellent adhesion: Ultrabase covered by microporous coating, shows strong adhesion in printing. Easy to take off models by hand or with a little help from the scrapper for very large models.
  • Ultrabase integrated with heated bed: Super Flatness, Fast and uniform heating
  • Durable: The special coating is inorganic and has a hardness of 8 Mohs, and it is capable to work at 400°C.
  • Easy to clean: Ultrabase is easy to clean by alcohol/water.


Trigorilla Mainboard:


Tri-Gorilla is a integrated main board that is integrated with the mighty function of the Mega2560+ramps 1.4 on respect of both software and hardware and has more premium features, a rich all-in-one electronics solution. Supports Marlin firmware too.


Technical specifications:

Printing Technology FDM (Fused Deposition Modeling)
Layer Resolution 0.05-0.3 mm
Positioning Accuracy X/Y 0.0125mm Z 0.002mm
Supported Print Materials PLA, ABS, HIPS, Wood
Print Speed 20~100mm/s(recommended speed 60%)
Travel Speed 150mm/s
Nozzle Diameter 0.4 mm/1.75 mm
Extruder Quantity Single
Build Size 210 x 210 x 205mm
Working Voltage 12V DC
Electrical 110-220V AC, 50/60Hz
Operational Extruder Temperature Max 260ºC
Ambient Operating Temperature 8ºC - 40ºC
Operational Print Bed Temperature Max 110ºC
Input Formats .STL, .OBJ, .DAE, .AMF
Slicer Software Cura
Cura Output Formats GCode
Connectivity SD Card, USB Port (expert users only)
Printer Dimensions 405mm x 410mm x453mm
Pakage Weight 16.5kg

Anycubic i3 Mega 3D Prints

Anycubic i3 Mega Ultrabase 3D Printer

Anycubic i3 MEGA 3D Printer with Ultrabase

Anycubic i3 MEGA 3D Printer with Ultrabase

Anycubic i3 MEGA 3D Printer with Ultrabase

Anycubic i3 MEGA 3D Printer with Ultrabase

Anycubic i3 MEGA 3D Printer with Ultrabase
