Qidi Tech X-Plus 3
The ability to print high-performance materials with ease, faster printing, combined with its user-friendly interface and innovative features, the Qidi X-Plus 3 is an attractive choice for businesses seeking greater efficiency at a competitive price.
QIDI TECH X-PLUS 3 FEATURES & HIGHIGHTS
- Ultra-Fast Printing Capability
- The Qid X-Plus 3 can print a Benchy in just 14-16 minutes - a feat that is made possible by its lightweight, hardened wear-resistant carbon fiber rods and CoreXY Structure and a 9.5:1 gear ratio. This ultra-fast printing capability can significantly increase productivity and save money by allowing one printer to do the work of many.
- Klipper firmware
- Controlled temperature chamber and drying box
- The Qidi Tech X-Plus 3 printer has a controlled temperature chamber and drying box that enable it to print high-performance materials such as ABS or PETG.
- The chamber can be heated to as high as 65°C, the extruder up to 350°C and the hot bed 120 °C. There are LEDs installed in order improve visibility during operation
- The printer's precise temperature control enables users to achieve superior print quality for even the most demanding materials.
- Resonance compensation & 16 point auto leveling.
- The Qidi X-Plus 3 is equipped with resonance compensation technology, which reduces printing vibrations to give you smoother and more precise prints.
- The printer has an inductive sensor that performs 16-point auto bed leveling.
- The advanced automatic leveling system works in conjunction with this feature to ensure hassle-free calibration and consistent high quality prints.
- Silent, Strong & Durability
- X-Plus 3 uses the TMC2209 for its X and Y axes, which feature sensor less home positioning. The Z axis is supported by optical limit switches; it also has dual lead screws. Linear rods are used in both Y and Z axes while carbon rods provide support to the X axis in order to provide more stability during operation.
- Double-sided flexible magnetic HF printing plate
- The 280x280x270mm print size of the printer makes it ideal for larger projects in a variety of industries.
- The X-Plus 3 comes equipped with a double-sided flexible magnetic HF printing plate, which makes it easy to remove printed models by bending the plate.
- Two types of Hot ends & its Flexibility
- The copper alloy nozzles are appropriate for printing regular filament types like PLA, PETG, and ABS.
- Hardened steel nozzles are suitable for abrasive filaments like carbon fiber—both sets have high flow rate nozzles capable of reaching up to 35mm/s³ and the maximum nozzle temperature can go up to 350C.
- The extruder has a 9.5 to 1 gear ratio, and in addition to the hotend part cooling fan—the printer features an auxiliary cooling fan on its right side.
- The flexibility provided by its interchangeable nozzle options enables users to tailor the printer's performance to their specific needs.
- Ease of installation & User-friendliness
- Ease of installation is another important aspect of the X-Plus 3. The printer comes fully assembled, reducing the amount of effort required to set up.
- This user-friendly approach extends to the software designed to work with the X-Plus 3, which is easier and more accessible than ever before—making printing a breeze for people of all skill levels.
- The printer is equipped with a 5” touch screen and supports WiFi as well as Ethernet network printing.
- Cost-effective solution
- The X-Plus 3 is an excellent choice for businesses that need a high quality printer without breaking the bank.
QIDI TECH X-PLUS 3 TECHNICAL SPECIFICATIONS
|Net weight (kg)||19.5|
Copper alloy nozzle hotend For Common materials
Hardened steel nozzle hotend For Abrasive materials
|Auxiliary Part Cooling Fan||Yes|
|Chamber Temperature Control||65°C Independent Chamber Heating|
|Chamber Circulation Fan With Activated carbon air filter||No|
|Screen||5.0 inch 480*272 touch screen|
|Seal print||Dryer Box + Desiccant|
|Connection Options||Wi-Fi/USB Flash Drive/Ethernet Cable|
|Compatible filament||PLA, ABS, ASA, PETG, TPU, PET-CF, PA12-CF, PC, UltraPA, Nylon, etc.|
|Z Axis||Double Z axis|
|X axis||Hardened Wear-resistant Carbon Fiber Rod|
|Printing Accuracy:||±0.1 mm|
|Bed Leveling:||Automatic Leveling|
|Extruder transmission ratio||9.5:1|
|Hot end:||Ceramic Heating Core|
|Extruder:||High-flow Direct Drive Extruder|
|Nozzle diameter:||0.4mm (0.2,0.6,0.8mm Optional)|
|Hot bed temperature:||120C|
|Printing Plate:||Double-Sided Flexible Magnetic HF Plate|
|Main Processer:||Cortex-A53,64-bit Processor 1.5Ghz,8G-EMMC,1G DDR3|
QIDI Print and other third-party software,
such as Ultimaker Cura, Simplify3D, PrusaSlicer, etc.
|Operating System:||Windows, MacOS, Linux|
|Assembled||Assembled and First Print within 10 minutes|
WHAT'S IN THE BOX
|X-PLUS 3D Printer + Dryer Box||Desiccant|
|500g filament||Power cord|
|Filament spool holder||Ethernet cable|
|Allen keys H1.5,2,2.5||Glue stick|
|7mm spanner||USB 2.0 flash drive|
|Flat head screwdriver||Spare parts kit|
|0.4mm nozzle cleaning tool||Ordinary hotend|
