Creality CR-10 V2 3D Printer
Main features of Creality CR-10 V2:
- An Improved and Sturdier Frame[Triangle Reinforcement Bar]
- Z-axis brace connecting the top of the frame to the base.This should give the printer an overall more sturdy frame, reducing vibrations, therefore less Z-wobble and ensuring a smoother finish of prints
- Double Cooling fans dissipate heat more quickly and efficiently prevents filament blockage producing better results and improving in print precision.
- All Metal Extruding unit - allows for stable feeding of filament and wear resisting thus leads to consistent and enhancement in print results
- Patented High Standard V Slot profile design
- Meanwell Power supply 24V 350 W
- Upgraded with latest silent Motherboad 2.5.2 with TMC2208 ultra mute driver .
- This gives an operating sound less than 50dB
- Hackable and upgradeable, Space reserved for BLTouch or any other sensor you can think for upgrades
- An Ultrabase-like build plate
- Carborundum Glass platform - Reduces Warping, Easy to remove the print once the bed is cooled.
- Improved UI navigation
- Resume-print function
- Filament runout sensor
Technical specifications
| Technology | FDM |
|---|---|
| Year | 2019 |
| Assembly | Pre-assembled |
| Mechanical arrangement | Cartesian-XZ-head |
| Manufacturer | Creality |
| Build volume | 300 x 300 x 400 mm |
| Layer height | 100 microns |
| Extruder Type | Single |
| Nozzle size | 0.4 mm |
| Max. printing speed | 180 mm/s |
| Max. extruder temperature | 260 °C |
| Max. heated bed temperature | 100 °C |
| Precision | ±0.1mm |
| Layer thickness | 0.1-0.4mm |
| Power supply | AC Input 115V/230V 24V Output |
| Power rating | 350W |
| Enclosed print chamber | No |
| Auto-leveling | Optional |
| Connectivity | SD Card |
| Build-in camera for monitoring | No |
| Average operating noise | 50 dB |
| Filament diameter | 1.75 mm |
| Third-party filament | Yes |
| Filament materials | PLA, ABS, PETG, TPU |
| Operating system | Windows (XP or higher), MacOSX, Linux |
| Recommended Slicer | Cura, Simplify3D |
| File types | STL, OBJ, AMF |
| Assembled dimensions | 420 x 550 x 650 mm |
| Weight | 11.5 kg |
Buyer Protection Policies
100% Secure Payment
PayPal-the most reliable payment method. Also accepts card payments(PCI DSS Compliant)
DHL,UPS Insured Shipment
High Quality Express Transport without damage.
1 Year Warranty
Just in case. Of course we only ship out perfect products.
Technical Support Service
Experiencing trouble? Feel free to contact us!
Shipping Details
Processing (Lead) Time
Out of stock
Delivery Time to Doorstep (Transit)
4 to 5 days via FedEx/UPS/DHL
| PRINTING SPECIFICATIONS | |
| Printing Technology | FDM |
|---|---|
| Build Volume | 300 x 300 x 400 mm |
| Number of Extruders | One |
| Precision | ±0.1mm |
| Print Speed | Normal 30-60 mm/s , Max 180 mm/s |
| Nozzle Diameter | 0.4 mm |
| Max Nozzle Temperature | 260 °C |
| Max. Heated bed temperature | 100 °C |
| Layer Height | 100 microns |
| Layer Thickness | 0.1-0.4mm |
| FILAMENT/MATERIAL SPECIFICATIONS | |
| Compatible with 3rd party materials? | Yes |
| Filament Diameter | 1.75 mm |
| Printable Materials | PLA, ABS, PETG, TPU |
| CONNECTIVITY(INTERFACE) | |
| SD Card Reader | Yes |
| FEATURES | |
| Built in Camera for Monitoring | No |
| Filament runout detection | Yes |
| Enclosed Build Chamber | No |
| Levelling | Optional |
| Print Pause & Resume | Yes |
| Average Operating Noise | 50 dB |
| SOFTWARE SPECIFICATIONS | |
| Supported Software/Slicing | Cura, Simplify3D |
| Supported OS | Windows (XP or higher), MacOSX, Linux |
| Supported File Formats | STL, OBJ, AMF |
| ELECTRICAL SPECIFICATIONS | |
| Input Power | AC Input 115V/230V |
| Power Consumption | 350W |
| Output Power | 24V Output |
| DIMENSIONS & WEIGHT | |
| Product Dimensions | 420 x 550 x 650 mm |
| Product Weight | 11.5 Kg |
