Ortur Laser Master 2
- The Laser Master 2 - 7W is good at picture engraving.
- The Laser Master 2 - 15W is the most cost-effective, available for both engraving and cutting.
- The Laser Master 2 - 20W is a higher power and supports faster engraving and cutting.
- Laser Master 2,20W - Second generation - LU2-4,12V
- Protective Laser shield around the head
- Small laser spot
- Better engraving and cutting effect
- Long life
- Easy to use
- Durable design
- Specialized Motherboard with STM32 MCU
- Ortur Metal Enclosure is now available for purchase.
- Fixed Focus UPDATED!
- A grounding kit will be supplied.
- Y-axis rotary roller system used for engraving on cylindrical objects such as engraving texts, patterns on cansOPTIONAL UPGRADE
- It could preprocess 32 instructions, support a baud rate as high as 921600, more powerful!
- The Most Advanced 32Bits Laser Engraver Firmware
- Ortur laser master firmware, smarter, faster, higher precision, and easier to use.
- Laser power range could be S0 - S1000, compared to 8bits desktop laser engravers, which only has S0 - S255, Ortur Laser Master could control laser beam more accurately, could even use the high power laser unit to "draw" a picture on paper, that the 8bits high power laser engravers could not do.
- Engraving speed could be as high as 3000MM/Min. ( If do not consider the laser carving result, the velocity of movement could be as high as 1000MM/S )
- Active Position Protection
- There is a G-sensor on the motherboard. If the machine detects unauthorized movement, the laser beam will stop.
- Laser Beam Safety Guard
- If your computer system is halted or the USB cable disconnected, the laser engraver stops moving. The laser beam will stop to prevent fire.
- Exposure Duration Detection and Limitation
- If the laser engraver is under control, but users forget to operate and keep the laser beam working, extra safety will cut off if the motor stopped moving to prevent fire.
- LaserGRBL ( free software ) supports Windows XP, 7, 8, 10. LaserGRBL is the most popular carving software in the world; it could import different format images, you could try editing in PhotoShop, Inkscape, CAD, etc., and then connect to the engraver via laser LaserGRBL for engraving and cutting.
- LightBurn ( paid software, lightburnsoftware.com ) supports Windows, Mac OS, and Linux. It's the most popular paid carving software in the world, straightforward to use.
- This laser engraver supports PWM mode.
- Pre-assembled parts just need 10 - 20 minutes to install the machine.
- 400 x 430 mm large engraving area.
- Aluminum profile frame + structured cabling, solid structure, smooth operation, attractive appearance
- Synchronizing shaft mechanical structure, avoid out-sync on two Y rails during full speed engraving.
- Motherboard: 32 bits motherboard with STM32 MCU
- Firmware: Ortur Laser Master Firmware
- OS of Upper Computer: Windows ( Working with LaserGRBL ), MAC OS and Linux ( Working with LightBurn )
- Power of Laser Engraver: 36W, 12V 3A
- Electrical Power of Laser Module: 7W, 15W, 20W
- Wave Length: 445 ± 5nm
- Variable Focus: Yes for 7W
- Fixed Focus: Yes for 15 W, 20W
- Default Focal Length: 55MM for 15W & 20W Laser Module; 58MM for 7W Laser Module
- Input Format: NC, BMP, JPG, PNG, DXF, etc.
- Carving Area: X: 400MM x Y: 430MM
- Carving Speed: 3000MM / Min and less
- Image size: No Limit ( The pixel accuracy could be adjusted freely, and the default is 300 pixels per inch, it's about 0.81um pixel precision )
- Please wear goggles when operating the laser engraver. Wear safety goggles to avoid blindness.
- Please do not touch the laser emitter with your hand, or it may burn your hand.
- Please avoid a strong impact on the machine.
- Children under 14 are not allowed to use this product, and children over 14 need adult supervision.
- The light engraving machine can not be directly applied to any mirror reflecting object, which may cause injury to the operator or burn the laser.
- This product is not recommended for industrial cutting due to its high engraving speed.
Ortur Laser Master 2 - Cutting & Engraving properties/Data Sheet.
